Duet3D Duet 2 Ethernet electronic controller card v1.05

€197.50 (coming soon)
€160.57 Excl. 23% VAT
Description Specifications
Description
The Duet Ethernet module is an advanced electronics board with a powerful 32-bit processor. Ideal for your 3D printer or CNC machine.

The Duet Ethernet has the following specifications:
  • 32-bit Processor
  • Ethernet module
  • TMC2660 stepper drivers with the possibility of 256 microsteps and 2.8A motor current
  • Fast SD card reader with support for a second SD
  • Dual extrusion on board and the option to connect 5 external step drivers
  • Powerful heated bed connection (18A)
  • Direct connection via Ethernet to PC, tablet or smartphone
  • Firmware update via web interface possible
  • All 3D printers are supported (Delta, Core XY, standard cartesian)
  • Connections for PanelDue full colour LCD touchscreen
  • Expandable to 7 extruders with firmware support for mixing nozzle systems
  • 3 Thermistor connections
  • 5 Endstop inputs
  • LCD connection
  • SD card onboard
  • SD card external
  • 5 Mosfets
The board comes with an SD card and separate molex connectors.
Specifications
Brand: Duet3D No of thermistors: 3
Input voltage: 12-24V Our item no: DUE00044
Dimensions: 128 x 100 mm
