Dyze Pulsar 220V large-scale pellet extruder, 3mm

Description

The Pulsar is a state-of-the-art and large-scale plastic pellet extruder. It is designed to print parts of 1m³ or more as quickly and cost-effectively as possible and can produce up to 500mm³ (2.5 kg/h) of material. The Pulsar is compatible with any large-scale 3D printer or even robotic arms.

The pulsar is designed with three heat zones. This ensures that the polymer remains at a constant temperature. The upper part receives the cold pellets and heats them to melting point. Next, the middle zone stabilises the polymer at a precise temperature. A nozzle heater ensures an even flow. This Pulsar also comes with a 3mm nozzle. On order, versions can be supplied with other nozzle diameters of 1mm or 5mm.

Technical information:

Screw diameter: 16mm
Screw length: 235mm
Maximum flow: 500 mm3/s or 2.5kg/h

Specifications

Brand:	Dyze Design	Nozzle temp range:	0 - 500 °C
Dimensions:	484 mm	Power rating:	1,100 W
Max RPM:	100 rpm	Our item no:	DYZ00017
Max temp:	500 °C	Voltage:	220 v
Nozzle diameter:	3 mm	Weight:	7 kg

Interested in ordering?

Click HERE to send us a mail and we'll alert you when it becomes available!

€10,345.00

(coming soon)

€8,410.57 Excl. 23% VAT

Dyze Sentinel filament detector, 1.75mm

Zoom in

Description

The Dyze Sentinel is a filament detector and gives a message if there is something wrong with the filament. In addition to the detection functionality, the Sentinel also makes the filament dust-free.

1.75mm and 2.85mm are supported and it is possible to connect multiple Sentinels using a daisy chain method for easy monitoring of multiple extruders.

The primary connection cable is included.

Specifications

Brand:	Dyze Design	Our item no:	DYZ00002
Current consumption:	31 ma	Voltage:	5 v
Dimensions:	18 x 58 x 29 mm

Extra Information Specifications (PDF)

€39.50

€32.11 Excl. 23% VAT

EU warehouse

Dyze stainless steel nozzle, 0.2mm

Zoom in

Description The Dyze stainless steel nozzles are of very good quality and last more than 12 times longer than brass nozzles and 24 times longer than aluminium nozzles.

Because the nozzle is made with a special temperature-resistant nut, it is possible to replace the nozzle at room temperature, which makes changing the nozzle even easier and prevents it from leaking.

The nozzle is suitable for filament with a diameter of 1.75mm and has an opening of 0.2mm.

Compatible with the following part:
		Dyze \| DyzEnd-X Hotend

Specifications

Brand:	Dyze Design	Nozzle diameter:	0.2 mm
Filament diameter:	1.75 mm	Our item no:	DYZ00003
Material:	Stainless steel	Screwthread type:
Nozzle coating:	none

Nozzle diameter:

€27.50

€22.36 Excl. 23% VAT

EU warehouse

Dyze stainless steel nozzle, 0.6mm

Zoom in

Compatible with the following part:
		Dyze \| DyzEnd-X Hotend

Specifications

Brand:	Dyze Design	Nozzle diameter:	0.6 mm
Filament diameter:	1.75 mm	Our item no:	DYZ00005
Material:	Stainless steel	Screwthread type:	M8x1,25
Nozzle coating:	none

Nozzle diameter:

€21.00

€17.07 Excl. 23% VAT

EU warehouse

Dyze stainless steel nozzle, 0.8mm

Zoom in

Compatible with the following part:
		Dyze \| DyzEnd-X Hotend

Specifications

Brand:	Dyze Design	Nozzle diameter:	0.8 mm
Filament diameter:	1.75 mm	Our item no:	DYZ00006
Material:	Stainless steel	Screwthread type:	M10
Nozzle coating:	none

Nozzle diameter:

€21.00

€17.07 Excl. 23% VAT

EU warehouse

Dyze stainless steel nozzle, 1mm

Zoom in

Compatible with the following part:
		Dyze \| DyzEnd-X Hotend

Specifications

Brand:	Dyze Design	Nozzle diameter:	1 mm
Filament diameter:	1.75 mm	Our item no:	DYZ00007
Material:	Stainless steel	Screwthread type:
Nozzle coating:	none

Nozzle diameter:

€21.00

€17.07 Excl. 23% VAT

EU warehouse

Dyze stainless steel nozzle, 1.2mm

Zoom in

Compatible with the following part:
		Dyze \| DyzEnd-X Hotend

Specifications

Brand:	Dyze Design	Nozzle diameter:	1.2 mm
Filament diameter:	1.75 mm	Our item no:	DYZ00008
Material:	Stainless steel	Screwthread type:
Nozzle coating:	none

Nozzle diameter:

€21.00

€17.07 Excl. 23% VAT

EU warehouse

Dyze PT100 temperature sensor

Zoom in

Description Measure temperatures up to 400°C with this PT100 temperature sensor from Dyze.

This thermistor from Dyze has been specially developed for the DyzEnd-X hot end and can easily be mounted in the heatblock thanks to the M5 screw thread. The cable has a length of 10cm and is equipped with a Molex connector of 15 x 5mm.

PLEASE NOTE: you must order the corresponding Dyze amplifier board separately.

Specifications

Brand:	Dyze Design	Max temp:	400 °C
Cable length:	10 cm	Our item no:	DYZ00014
Connector A:	Molex 2 pin female	Screwthread type:	M5

€30.50

€24.80 Excl. 23% VAT

EU warehouse

Dyze thermistor with Molex connector 500°C

Zoom in

Description With this Dyze thermistor you can take accurate temperature measurements up to 500°C!

The thermistor features a Molex connector and an M5 thread for easy attachment of your Dyze hot end. The cable is provided with a black shrink tube and has a length of 10.2cm. At a temperature of 20°C the resistance is 5.2 MΩ and at 400°C it is 250 Ω.

CAUTION: Please update your firmware before getting started with this thermistor.

Specifications

Brand:	Dyze Design	Our item no:	DYZ00009
Cable length:	10 cm	Resistance tolerance:	500 °C

€30.50

€24.80 Excl. 23% VAT

EU warehouse

Dyze filament sentinel, 2.85mm

Zoom in

Description With the Filament Sentinel from Dyze, filament congestion is a thing of the past!

Prevent failed 3D prints with this filament detector that gives a signal when something is wrong with the filament. In addition, the detector cleans the filament and is easy to mount on your single or dual extruder 3D printer. Attach one or more sentinels to the filament spool holder or in front of the extruder for optimal operation. Suitable for any type of filament with a diameter of 2.85mm.

Note: Does your 3D printer not have an LCD screen? Then the sentinel only works with an Octoprint/OctoPi.

Download the specifications here.

Specifications

Brand:	Dyze Design	Our item no:	DYZ00013
Current rating:	31 ma	Screwthread type:	M8
Filament diameter:	2.85 mm	Voltage:	5 v
Max operating temp:	70 °C

Order now, we can ship this today!

€39.50

€32.11 Excl. 23% VAT

In stock

Capricorn XS heat break liner, 2mm x 3mm (300mm)

Zoom in

Description The Capricorn XS heat break liner is specially made to fit perfectly in the heatbreak. The liner is also 30cm long so you can provide for 10 heat breaks.

Specifications

Brand:	Capricorn	Length:	30 cm
Colour:	dark blue	Material:	PTFE
Filament diameter:	1.75 mm	Outer diameter:	3 mm
Inner diameter:	2 mm	Our item no:	DBW00066

Interested in ordering this machine?

Click HERE to send us a mail and we'll alert you when it becomes available!

€12.50

(coming soon)

€10.16 Excl. 23% VAT

Heaterblock insulation cotton

Zoom in

Description This 3mm thick insulation cotton is suitable to insulate your heater block so that less heat is lost. This keeps the temperature of your hot end more stable, which in turn results in better prints.

Specifications
